2D DRAWINGS & PLANS
This is where ideas turn into precise, buildable documents. We take the approved concept and develop clear 2D plans—site plans, floor plans, key sections, and service overlays—so everyone from client to contractor is on the same page. Dimensions, levels, and notes are laid out cleanly, coordinated with structural and MEP inputs, and prepared to meet local submission requirements in Pakistan.
- Accurate, dimensioned plans ready for site use
- Clean CAD layering and naming for easy updates
- Coordinated with structure and MEP to avoid clashes
- Submission-ready sets as per local by-laws (e.g., DHA/CDA/LDA)
Site Data & Measurements
Drafting & Coordination
Review & Issue Set
Frequently asked questions
Typically: site plan, floor plans with dimensions, key sections, door/window notes, and service overlays (as needed). Scope can be adjusted per project.
Usually 2–14 days depending on project size, number of revisions, and availability of surveys.
Editable DWG and print-ready PDFs (A1/A3 with title blocks, legends, and north arrow).
Yes. We can redraw, standardize layers, and bring everything to a clean, consistent set.
We usually plan for two to three rounds during this stage; larger changes can be added to scope if needed.
